Description
ICON's 4.5" Stage 1 System is comprised of 4.5” lift coil springs optimized for trucks equipped with diesel engines with a dual rate design that allows for a softer initial rate for superb on-road comfort and a firmer secondary rate that increases during compression for excellent bottoming resistance and off-road performance. Fabricated radius arm drop brackets correct suspension geometry and ensure proper wheel alignment with the OE radius arms. The fabricated track bar drop bracket allows the axle to be properly centered under the frame and reduces road feedback throughout the steering system with improved on- and off-road manners thanks to the elimination of bump steer. Heavy-duty fabricated 5" rear blocks and U-bolt kit lift the rear of the vehicle and are designed to withstand heavy towing/hauling duty as well as the stresses of aggressive off-road use. ICON 2.0 Aluminum Series internal reservoir front and rear shocks feature a vehicle specific tune for improved vehicle handling and excellent ride quality on- and off-road. The included box kit includes fabricated front sway bar drop brackets to prevent bind, heavy-duty aluminum bump stop spacers, and high quality stainless steel extended brake lines.
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
This Part Fits:
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
- ICON 2.0 Aluminum Series internal reservoir shocks feature vehicle specific tune for superior performance and ride quality
- ICON engineered dual rate coil springs deliver 4.5" of front lift with exceptional vehicle control over varying terrain
- Lifetime guarantee against ICON fabricated component breakage or manufacturer defect
- Radius arm drop brackets correct geometry and caster for optimal alignment specs
- Track bar drop bracket reduces track bar angle and corrects bump steer geometry
- Lifetime guarantee against coil spring breakage or sagging
- Corrosion resistant anodized shock bodies with 5/8" shafts
- Approximately 50% increased front wheel travel over stock
- Fits 2023-2025 F-250 / F-350 4WD diesel applications
- Shocks are fully rebuildable and re-tunable
- Stainless steel braided front brake lines
- Heavy-duty fabricated rear lift blocks
This Part Fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2023-2025 | Ford | F-250 Super Duty | King Ranch |
| 2023-2025 | Ford | F-250 Super Duty | Lariat |
| 2023-2024 | Ford | F-250 Super Duty | Limited |
| 2023-2025 | Ford | F-250 Super Duty | Platinum |
| 2023-2025 | Ford | F-250 Super Duty | XL |
| 2023-2025 | Ford | F-250 Super Duty | XLT |
| 2023-2025 | Ford | F-350 Super Duty | King Ranch |
| 2023-2025 | Ford | F-350 Super Duty | Lariat |
| 2023-2024 | Ford | F-350 Super Duty | Limited |
| 2023-2025 | Ford | F-350 Super Duty | Platinum |
| 2023-2025 | Ford | F-350 Super Duty | XL |
| 2023-2025 | Ford | F-350 Super Duty | XLT |
