Description
Mounts directly to frame. Max grill guards bolt directly to the tray. Accommodates up to 12000 pound winches. No drill installation.
Installation Instructions
This Part Fits:
Installation Instructions
- Fits most medium frame 8,000-12,000 lbs winches up to 10.25" tall
- Winch tray tested to a maximum straight line pull of 16,500 lbs
- Pre-drilled for quick mounting of hawse or roller fairlead
- Optional MAX Tow Hooks (Part No. 46-3005 - 2 needed)
- HD brackets mount directly to vehicle frame
- MAX Grill Guards Bolt Directly To Tray
- Accommodates Up To 12000 lb. Winches
- Optional MAX Bull Bar/Light Bar
- Mounts Directly To Frame
- Optional MAX Faceplate
- No Drill Installation
This Part Fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2010-2014 | Ford | F-150 | FX2 |
| 2009-2014 | Ford | F-150 | FX4 |
| 2010-2012 | Ford | F-150 | Harley-Davidson Edition |
| 2009-2014 | Ford | F-150 | King Ranch |
| 2009-2014 | Ford | F-150 | Lariat |
| 2011 | Ford | F-150 | Lariat Limited |
| 2013-2014 | Ford | F-150 | Limited |
| 2009-2014 | Ford | F-150 | Platinum |
| 2009-2014 | Ford | F-150 | STX |
| 2010-2014 | Ford | F-150 | SVT Raptor |
| 2009-2014 | Ford | F-150 | XL |
| 2009-2014 | Ford | F-150 | XLT |
